Refrigerant used in water-cooled chiller systems is the vital working medium that enables the entire cooling process. It is the substance responsible for absorbing heat from the chilled water loop and transferring that heat to the condenser water, which is then released into the atmosphere via a cooling tower.
The choice of refrigerant not only influences chiller performance and energy consumption but also significantly impacts environmental sustainability, safety, and system design. Over the years, refrigerant technology has transitioned from ozone-depleting substances to environmentally friendly, low-GWP (Global Warming Potential) refrigerants, aligning with global climate regulations like the Montreal Protocol and Kigali Amendment.
What is a Refrigerant in a Water-Cooled Chiller?
In a water-cooled chiller, the refrigerant circulates in a closed-loop cycle through four primary components:
- Evaporator – absorbs heat from the building’s chilled water circuit.
- Compressor – increases the pressure and temperature of the vaporized refrigerant.
- Condenser – transfers heat from the refrigerant to condenser water.
- Expansion Valve – drops the pressure of the liquid refrigerant to begin a new cycle.
Throughout this process, the refrigerant repeatedly changes phase (liquid ⇌ vapor), enabling efficient heat transfer.
Key Criteria for Selecting Refrigerants
When selecting refrigerants for water-cooled chillers, manufacturers and engineers consider:
- Thermodynamic Efficiency – Refrigerant must offer strong cooling capacity (BTU/lb or kJ/kg).
- Environmental Impact – Low GWP and zero ODP (Ozone Depletion Potential).
- System Compatibility – With materials, compressors, oils, seals.
- Toxicity and Flammability – According to ASHRAE safety classifications (A1, A2L, B1, etc.).
- Operating Pressure Levels – Must match the compressor and system design.
- Market Availability and Lifecycle Cost – Accessibility and long-term costs.
Types of Refrigerants Used in Water-Cooled Chillers
R-134a (Tetrafluoroethane)
- Type: HFC
- ODP: 0 | GWP: ~1300
- Commonly used in medium-pressure centrifugal and screw chillers.
- Non-flammable, non-toxic, and thermally stable.
- Has a long service history, but due to high GWP, it is being phased down globally.
R-123 (Dichlorotrifluoroethane)
- Type: HCFC
- ODP: 0.02 | GWP: ~77
- Used in low-pressure centrifugal chillers for decades due to its high efficiency.
- Good thermodynamic performance, but contains chlorine and is ozone-depleting.
R-513A (HFO-HFC Blend)
- Type: A1-rated blend of R-134a and R-1234yf
- ODP: 0 | GWP: ~630
- Designed as a low-GWP replacement for R-134a in existing and new systems.
- Compatible with R-134a compressors with little or no redesign.
R-1234ze and R-1234yf (HFOs)
- Type: Hydrofluoroolefins (next-generation refrigerants)
- ODP: 0 | GWP: < 1
- Ideal for new-generation centrifugal and screw chillers
- Classified as A2L (mildly flammable), requiring modified safety measures
R-717 (Ammonia)
- Type: Natural Refrigerant
- ODP: 0 | GWP: 0
- Used in industrial water-cooled chiller systems, especially in food processing and cold storage
Refrigerant Trends and Regulatory Influence
Global mandates are shaping refrigerant choices:
- Montreal Protocol phased out high ODP refrigerants like R-22 and R-123.
- Kigali Amendment calls for the reduction of high-GWP refrigerants like R-134a.
- F-Gas Regulations in Europe and similar global policies are forcing a shift toward low-GWP options.
Chiller manufacturers now invest in:
- HFO-compatible compressors and seals
- Safety upgrades for mildly flammable refrigerants
- Systems optimized for reduced refrigerant charge
Refrigerant used in water-cooled chiller applications plays a decisive role in balancing energy efficiency, cooling capacity, system compatibility, and environmental responsibility. As the HVAC industry shifts toward climate-friendly and regulatory-compliant alternatives, modern chillers are increasingly using low-GWP refrigerants such as R-513A, R-1234ze, and natural refrigerants like R-717.
With proper system design, safety protocols, and future-ready planning, businesses can ensure their water-cooled chillers not only deliver peak performance but also support a greener, regulation-compliant future. Choosing the right refrigerant is no longer just a technical decision — it’s a commitment to sustainable engineering.
